Size File: 4.4 GB

InventorCAM – CAD / CAM system developed by a new generation of Israeli firm SolidCAM Ltd (official distributor in Russia – Consistent Software).

This system is a complete solution for the automation of the production of metal. Using a wide range of proposed strats InventorCAM turning, milling, turning, milling and electrical discharge machining process eeer can in a short to prepare the necessary set of control programs for machining products.

Functionality InventorCAM

Support for 64bit computing by having a special version for 64bit

2.5-axis milling

InventorCAM provides high efficiency and accuracy 2,5-axis milling parts. Supports different strats for handling items such as contour, sampling (including islands) and the groove as well as various types of hole machining: drilling, reaming, threading, etc. The system has a wide range of possibilities 2,5-axis machining of analytic surfaces..

3-axis milling

InventorCAM provides a wide range of tools that can be effectively used for the treatment of articles with complex geometries (dies, molds) and prismatic parts. As the geometry for 3-axis machining using a three-dimensional solid model or surface. System supports a variety of strats for roughing and finishing, such as raster processing with a predeteed or automatically deteed by the raster angle of equidistant, projection processing, handling at the waterline, etc.

In addition to the listed capacity 2,5 and 3-axis machining, InventorCAM provides tools to identify and refine areas not treated in previous transitions. You can create a database of standard processes. Once created, a parameterized process can be reused in the future, which significantly reduces the of preparation of production, enhances the reliability of the developed programs, unifies the style of technological development, ensures that only the best processing technology and ensures the independence of the human factor. Lack zarezany guaranteed by the presence of means of control and visualization of machining.


InventorCAM offers various tools for creating control programs of the multi-processing on 4- and 5-axis machining centers. The model is set in a user-plane processing, after which the system automatically calculates all necessary parameters for the displacement and rotation of zero items. As a result, significantly reduces set-up of transition and increases accuracy.

Lathes and milling

InventorCAM has lots of features to automate the creation of control programs for turning and turning and milling. InventorCAM supports different types of tools that can effectively perform loudinal turning, facing, grooving and others. In addition InventorCAM automatically perform roughing and finishing of complex contours. Support rotating tool allows you to perform milling and drilling transitions to processing centers.

Electrical discharge machining

The proposed set of strats InventorCAM Wire EDM allows processing of external and internal contours of constant and variable angle. The possibility of 4-axis machining. A special algorithm prevents fall of the treated material. InventorCAM provides user controls physical processing parameters on the entire trajectory of the wire.

What News?

Read: InventorCAM_Release_Notes_2020_SP3_HF3.pdf
